Multifunctional SuDS tree surround
GreenBlue Urban’s compact SuDS tree pit surround, StormFormTM – part of the ArborFlow family – has been developed as an effective means of managing surface water run-off through tree pits. Ideal for use in urban areas where space is at a premium, StormFormTM handles extreme rainfall events in urban areas with ease.
With super-fast flow through rates and large storage capacity, StormFormTM is perfect for attenuating peak flows during the most extreme storm events and directing the water right into the tree pit where pollution and further capacity storage is available.
StormFormTM is an ingenious multi-functional system combining stormwater capture and storage, silt/debris capture, root control, primary irrigation and tree grille all on one easy to assemble, robust unit.
|Product Codes||Description||Nominal size||Water storage||Flow rate|
|SF100A||StormFormTM 100 Series SUDs System||1000mm x 1000mm||202 ltrs||10,000 ltrs/hr|
|SF200A||StormFormTM 200 Series SUDs System||1750mm x 1000mm||293 ltrs||15,000 ltrs/hr|
|SF300A||StormFormTM 300 Series SUDs System||1750mm x 1750mm||384 ltrs||19,000 ltrs/hr|
||Gulley gratings can be designed and manufactured to order to match existing aesthetics / architectural designs
Gulley gratings can be manufactured in different metals, e.g. bronze, stainless steel; or powder coated in any colour
Larger configurations can be created from individual components, or installed in linear applications
|6 monthly inspection – cleaning out debris and silt as required|
