FTS Clyde Tree Grille

Short description

Fabricated steel tree surround

  • Heavy duty galvanised support frame
  • Galvanised mild steel fabricated segments
  • Integrated irrigation system
  • Anti-theft lugs
  • Stainless steel fixings
  • Fully compatible / integrates with GBU below ground systems
  • Prevents compaction of soil
  • Enables water to freely access rooting area
  • Can be disassembled if needed for major tree maintenance
  • Design and built to be strong enough for light vehicular overrun
Code Outer Dimensions Central Aperture
CLYDE10GB 1000mm 500mm
CLYDE12GB 1200mm 600mm
CLYDE15GA 1500mm 600mm

Product Includes

  • Galvanised steel segments
  • Galvanised steel frame
  • RootRain Hydrogrille irrigation system
  • Stainless Steel fixings

Note, Clyde grilles are not suitable for vertical tree guards

Vehicle overrun: Maximum 1.5 tonne SMWL (Slow Moving Wheel Load)

Material: Mild galvanised steel (Bespoke options: Stainless Steel grade 304, Stainless Steel grade 316, Corten Weathering Steel)

Finish

  • Hot dip galvanised to BS EN ISO 1461:2009
  • Mean coating thickness 70μm / 505g/m2
  • Powder coated version also available, please enquire

Accessories: Spare fixing kit

Maintenance: Visual periodic inspection of irrigation/aeration inlets: Remove, clean and replace filter brush periodically.

Bespoke Options:

  • Full design and development service available
  • Heel safe / DDA requirements
  • HGV loading requirements
  • Slip resistance requirement
  • Full range of RAL colours available to order
